252
FIRST AID - PARAMEDICAL - EMERGENCY
HOSPITAL PULSE OXIMETERS
• 34290 MD-600 PULSE OXIMETER with alarms
• 34291 MD-630 PLUS PULSE OXIMETER
with alarms, printer and PC connection (USB)
Small, light-weight pulse oximeters with high accuracy and
reliable performances:
- adjustable SpO
2
and pulse alarm settings
- quick assessment of oxygen saturation and pulse rate
- hand-held unit, easy to operate
- with SpO
2
and pulse rate display
Pulse oximeter with printer and USB
Code 34291 with built-in thermal printer allows immediate
data printing. Moreover it provides 36 hours memory (with
interval of 6 seconds) or 24 hours (with interval of 4 seconds)
with possibility to recall up to 100 records (print out the last
records up to 240 seconds). Tone function and adjustable
volume. Safe, fast and convenient it becomes the essential and
most important equipment in first aid, ICU and anesthesiology
system.
• 34295 THERMAL PAPER - for code 34291
• 33704 PC-SMART LINK SOFTWARE - for code 34291
TECHNICAL SPECIFICATIONS (codes 34290-34291)
Oxygen saturation range: 0% to 100%
Pulse rate range:
30 bpm to 250 bpm
Display:
oxygen saturation, pulse rate, a pulse search
indicator, low battery indicator
SpO
2
accuracy:
± 2% between 80% to 100%
± 3% between 65% to 79%
below 65% not specified
Pulse accuracy:
± 1% of full scale
Range alarm setting:
SpO
2
upper limit: 100%
SpO
2
lower limit: 50%
pulse rate upper limit 250 bpm
pulse rate lower limit 30 bpm
Power requirements:
DC 6 volts by 4 alkaline AA size batteries
AC adapter output DC 6 Volts, 600 mA
Dimensions:
172x90x36 mm (34290) - 170x88x44 mm (34291)
Weight:
240 g - 300 g (34291) - without battery
Warranty:
1 year (SpO
2
sensor 6 months)
STANDARD ACCESSORIES (codes 34290-34291)
1 AC/DC Adaptor
4 AA Batteries - alkaline
1 Carrying bag
1 SpO
2
standard adult sensor
1 User manual (English, Italian, French, Spanish)
With
24 hours
memory
0434
Time
SpO
2
Pulse
USB Output port
for PC data
download
24/36 HOURS MEMORY
BUILT-IN THERMAL PRINTER
100 RECORDS OF
RECALL MEMORY
USB PORT
Easy analysis of patient
data and statistics
33704
ETCO
2
+SPO
2
PORTABLE OXI-CAPNOGRAPHY MONITOR
• 33702 OXY CAPNOGR. HUMAN
• 33703 OXY CAPNOGR. VET
Portable multifunctional Capnography
monitor providing SpO
2
, pulse, EtCO
2
,
Respiration with accuracy
and reliable performance.
Light and large LCD display
providing graphical SpO
2
,
EtCO
2
and Trend function all in one
design. Through optional software
link to PC via USB. Supplied with
adult sensor, AC adapter,
sampling tube, airway adapter,
filter cartridge, carrying bag,
4 AA rechargeable batteries.
• 34281 BPM-200 PULSE OXIMETER
with monitor, printer output and installed battery
The portable BPM-200 is an electronic pulse oximeter for
measuring oxygen saturation of arterial blood and pulse rate of
patient. Plethysmographic waveform display up to 12 hours of
patient trends. Finger adult probe and battery are included.
• 34287 BATTERY FOR BPM-200
• 33730 SpO
2
FINGER-PROBE - adult or child over 15 kg
Auto gain control for fast response and
accurate measurements
Long battery life: 4 hours
(20 hours for full charging)
LCD display: 240 x 64 mm
Handle
for transport
TECHNICAL SPECIFICATIONS
Power supply: 100-240 V, 50/60 Hz
Battery pack: lead acid battery pack (12 Volt)
Range: saturation 35-100%;
pulse rate: 30-250 bpm
Output for SpO
2
and pulse rate
Size: 75x225x175 mm - 3.5 kg
User manual (English, Italian)
Made in Korea
Nellcor compatible
output for SpO
2
probes
34281
SPO
2
PLETHYSMOMONITOR
TECHNICAL SPECIFICATIONS
Range
Accuracy
SpO
2
Saturation:
0% to 100%
±2% between 80% to 100%
Pulse Rate:
30 bpm to 250 bpm
±1% of full scale
Range
Average
EtCO
2
:
0 mmHg to 100 mmHg
4 breaths of EtCO
2
Respiration:
0 l to 99 l
8 breaths of respiration rate
Memory: 72 hours
Output interface: USB
Default Alarm Settings:
SpO
2
upper limit: 100%
SpO
2
lower limit: 50%
Pulse rate upper limit: 250 bpm
Pulse rate lower limit: 30 bpm
EtCO
2
upper limit: 100 mmHg
EtCO
2
lower limit: 0 mmHg
Resp upper limit: 99 bpm/min
Resp lower limit: 0 bpm/min
Power 4 AA rechargeable batteries 6 volts or AC/DC adapter
• 33705 FILTER - box of 10
• 33706 SAMPLING TUBE 1.2 m - box of 20
• 33704 PC SMART LINK SOFTWARE - optional
For analysis of patient data, statistics of
SpO
2
/Pulse/EtCO
2
/Resp. distribution
Size: 170x88x44 mm
72 hours
memory
with trend
function
34291
Weight:
240 g
34290
