251
FIRST AID - PARAMEDICAL - EMERGENCY
• 35100 OXY-50 PULSE OXIMETER - with software
Pocket fingertip pulse oxymeter with colour display
for both routine check and continuous monitoring
use.
Main features:
- display: 1.8" colour OLED
- resolution: 160x128
- alarm sound, pulse tone
- power supply: DC3V, <100MA
- record: data can be recorded up to 24 hours
- alarm: adjustable high and low limits
- PC software for transfering real time data
OXY-50 HANDHELD PULSE OXIMETER
TECHNICAL SPECIFICATIONS
Display mode (OLED display)
Pulse oxygen saturation (SpO
2
): 2 digits
Pulse rate (PR):
3 digits
Pulse intensity:
bar-graph
Pulse rate
Measuring range:
25bpm~250bpm
Resolution:
1 bpm
Accuracy:
±2bpm or ±2%
Average pulse rate:
Moving calculate the average
pulse rate every 4 cardio-beat's
cycle. Deviation between
average value and true value
does not exceed 1%
Pulse intensity
Range:
Continuous bar-graph display,
the higher display indicates the
stronger pulse
Battery:
dry battery (2AA)
Oxymeter probe:
wavelength: 660nm - 880nm
Dimension:
110(L)x60(W)x23(H) mm
Weight:
about 180g (with dry battery 2AA)
SpO
2
Measuring range:
0%~100%, (resolution 1%)
Accuracy:
70%~100%: ±2%
Average value:
Calculate the average value
every 4 measure value
Deviation between average
value and true value does not
exceed 1%
Safe type:
BFType
Supplied with one adult probe, 2 AA batteries, USB cable
PC software (English, Italian, Polish) and user manual
(English, French, Italian)
OXY-100 HAND-HELD PULSE OXIMETER
TECHNICAL SPECIFICATIONS
Oxygen saturation range: 35% to 100%
Pulse rate range: 30bpm to 240bpm
Perfusion index (PI) range: 0.2% to 20%
Display: oxygen saturation, pulse rate, pulse strength,
low battery indicator, perfusion index
SpO
2
accuracy: greater than 3% for SpO
2
range from 70% to 100%
Accuracy defined as root-mean-square value of
derivation according to ISO 9919
Pulse accuracy: ± 2% of full scale
Range alarm setting: SpO
2
upper limit: 95%
SpO
2
lower limit: 85%
pulse rate upper limit 100 bpm - 240 bpm
pulse rate lower limit 30 bpm - 60 bpm
Power requirements: 3 alkaline AA size batteries 4,5 V
continuous working time >30 hours
Dimensions: 145x74x29 mm - Weight: 210 g
Warranty: 1 year
• 34342 OXY-100 PULSE OXIMETER
Compact pulse oximeter for hospital and rescue
applications to monitor SpO
2
pulse rate, and
perfusion index(PI). SpO
2
can be displayed in
numbers with bar-graph of pulse as well as full
display of plethysmogram.
Includes adult SpO
2
sensor and extension cable.
Features:
- high accuracy and repeatability
- visual and audible alarm, with adjustable limits
- 384-hours data storage and review (with
1/2/4/8 sec.)
- automatic power-off
• 34344 SOFTWARE
This software allows to download and store all
measurements on a PC through USB port.
• 34345 ADULT SpO
2
CLIP PROBE - spare
• 34351 ADULT SpO
2
RUBBER PROBE
• 34347 PEDIATRIC SpO
2
PROBE
• 34348 EXTENSION CABLE -
for 34345-34347-34351
Output for USB
Veterinary oximeter see page 313
Portable and
lightweight
High resolution LCD display, backlight to display
SpO
2
, PR, Pulse Bar, Pi, and Plethysmogram
Battery status
display
3 ways switchable
display to show:
numbers, number and
waveform, waveform
35106
35107
35108
Pediatric probe - reusable
Infant probe - reusable
Extension cable (necessary for 35107, 35109)
Reusable SpO
2
adult probe
Reusable SpO
2
adult rubber probe
Reusable pediatric SpO
2
probe
Extension cable for 34345, 34347, 34351
34345
34351
34347
34348
GIMA
code
ACCESSORIES OXY-50
35105
Adult probe >15 kg - reusable - spare
35106
Pediatric probe 3-15 kg - reusable
35107
Neonatal probe < 3 kg - reusable
35109
Neonatal probe - disposable
35108
Extension cable necessary for 35107, 35109
35109
Neonatal probe - disposable
