FIRST AID - PARAMEDICAL - EMERGENCY
• 35090 OXY-3 OXIMETER - blister
Easy to use pocket device, measures oxygen
level and pulse rate.
Main features:
- simple operation, small & lightweight design, portable
- display SpO
2
, SpO
2
waveform, PR, Pulse bar
- low power consumption
- 2 AAA alkaline batteries included
- low battery indication, auto power off
- accommodates widest range of finger
sizes from pediatric to adult
- soft silicone padding, strong slip
- resistant clip, non-invasive, no pricking
- 4 direction display
- user manual in GB, IT, ES, FR
• 35075 SILICONE COVER - light blue
• 35076 CORDURA BAG with belt
loop - blue
OXY-5 AND OXY-6 PROFESSIONAL OXIMETERS
• 34282 OXY-5 FINGERTIP OXIMETER
• 34265 OXY-5 PEDIATRIC FINGERTIP OXIMETER
• 34285 OXY-6 COLOUR FINGERTIP OXIMETER
To monitor pulse oxygen saturation and pulse rate through
patient’s finger (10-22 mm finger thickness for 34282,34285 -
8-16 mm finger thickness for 34265) in medical and hospital
environments.
Main features:
- SpO
2
and pulse rate measurement
- bargraph of pulse rate
- perfusion index display. P.I. is a numerical value that indicates
the blood perfusion condition at the sensor site. It is a relative
value that varies from patient to patient and from measuring site
- high accuracy and repeatability: products are manufactured
by GIMA (in P.R.C. facilities) under strong quality controls
guaranteed by Italian notified body (CE 0476 CERMET)
- accuracy from the first reading in few seconds thanks to a
unique noise rejecton capability feature
- extra stability against motion during measurement (finger
bending, Parkinson's disease, hand movement, button pressing)
- audible and visible alarms
- automatic power on and power off when finger is out
- low voltage alarm display
- 8 language manual (GB, FR, IT, ES, DE GR, PT, Arabic)
- 50 hours working time with full batteries (30 hours for oxy-6)
- supplied in plastic case with batteries and pouch
- 4 direction adjustable display (oxy-6 only)
• 35076 CORDURA BAG with belt loop - blue
0476
0476
BACKLIT
DISPLAY
OLED
COLOUR
DISPLAY
DUAL COLOUR
OLED DISPLAY
DUAL COLOUR
OLED DISPLAY
OXY-3 OXIMETER
TECHNICAL SPECIFICATIONS
Pulse rate:
SpO
2
:
Perfusion:
Index:
RANGE
30-240 bpm
35%-99%
0-20%
ACCURACY
± 2 bpm (2%)
± 2% (75-99%)
± 3% (50-75%)
± 0.1% (0,2-2%)
± 0.2% (2-10%)
RESOLUTION
1bpm
1%
0-1%
Alarm:
SpO
2
: low limit 90%
Pulse rate: low: < 50 bpm - high > 120 bpm
Power:
1.5V (AAA size) alkaline battery x 2
Norms:
IEC 60601-1-2 Class II
LCD Display:
oxygen saturation, pulse rate, low battery indicator
Size - weight: 6.6x3.6x3.3 cm - 60 g including batteries
Italian manufacturer (made in P.R.C.)
0476
34282
35090
34285
34285
• 35091 OXY-4 OXIMETER - blue
• 35092 OXY-4 OXIMETER - orange
• 35093 OXY-4 OXIMETER - other colour (minimum 100 pieces)
Select colour with order
Fingertip pulse oxymeter to monitor pulse oxygen saturation,
pulse rate, and perfusion index.
- it is light, small in size and easy to take
- accurately measures SpO
2
value and pulse rate value
- dual-color display of SpO
2
, PR, PI, Plethysmogram and pulse bar
- measuring range, SpO
2
35 - 99%, Pulse rate 30 - 240 bpm
- innovative 4 directions display
- automatic power On/Off
- more than 30 hours continuous working with 2AAA alkaline batteries
- audible and visible alarm function
- battery voltage indication, low battery voltage alarm
- prevention against water ingress, drop resistant
- manual in 8 languages: GB, FR, IT, DE, ES, PT, GR, PL
• 35076 CORDURA BAG with belt loop - blue
2179
Size: 66x36x33 mm
OXY-4 COLOUR OXIMETER
oximeters -
see page 2
35091
35092
