FIRST AID - PARAMEDICAL - EMERGENCY
MINDRAY PM-60 PULSE OXIMETER
Performance specifications
Display:
2.4“ color TFT Resolution: 320x240
Multi dispays selectable: standard or waveform screen
Trace:
1 plethysmogram waveform
Indicator:
alarm indicator light, power indicator light,
pulse tone, alarm sound, button tones
Interface:
dual-purpose socket for connecting SpO
2
sensor and communication cable
IR interface: infrared link allows downloading
realtime patient data to computer
DC power interface: Charger stand for Li-ion battery
DC power requirements: input voltage 5V DC Power 1.2A
Battery:
Li-ion battery 24 hours continuous working
3xAA batteries 36 hours continuous working
Trend memory: Monitoring mode: Resolution: 2s
Maximum time: 96 h
Spot-checkmode Reviewof up to 4,000 data
Measure up to 99 patients
Alarm:
user adjustable high and low limits
3-level audible and visual alarm
SpO
2
Measurement range: 0~100% ±2% (70~100%)
Resolution: 1%
Alarm range: 50~100%
Refreshing rate: 1 s
Averaging time: 7 s (sensitivity set HIGH)
9 s (sensitivity set MED)
11 s (sensitivity set LOW)
Pulse rate
Range:
18~300 bpm (±3 bpm non-motion)
(±5 bpm motion)
Resolution: 1 bpm
Alarm range: 18~300 bpm
Refreshing rate: 1 s
Averaging time: same as SpO
2
Type of protection: Class II with internal electric power supply
Degree of protection: BF (defibrillation proof)
Protection against ingress of liquid: IPX 2
TECHNICAL SPECIFICATIONS
PALM SAT
®
2500A NONIN PULSE OXIMETER
TECHNICAL SPECIFICATIONS
SpO
2
range:
0% to 100% ±2 (70-100% without movement)
Pulse rate range: 18 to 321 bpm ±3 (18-300% without movement)
Power:
4AA alkaline batteries 1.5 V (for 60 hours use)
optional NiMH rechargeable battery (for 40 hours use)
Size:
7x13.8x3.2 cm
Weight: 213 g
GIMA
code
35087
Adult reusable rubber probe (12.5-25.5 mm) - 1 m cable
35088
Pediatric reusable rubber probe (10-19 mm) - 1 m cable
35089
Charger stand with NiMH battery pack, plug kit
35082
VISION software for data management (GB)
35083
Adaptor for USB - PC connection
ACCESSORIES SAT 2500
Easy 2 button
operation
Audible and
visible alarms
Three-coloured
signal quality
indicator
Rugged rubberized
case with IPX 2
level of liquid ingress
protection
Blinking alarm
silence indicator
Low battery
indicator
Bright LED display
of SpO
2
and
pulse rate
0123
• 35086 PALM SAT
®
2500A PULSE OXIMETER with rubber
reusable adult probe and alarm
.
A compact versatile and reliable pulsoximeter designed and
tested to exceed all durability requirements.
Main features:
- Pure Sat
®
technology offers accuracy & speed in getting a
reading, even with varying skin pigmentations or polish and
is able to monitor, with declared accuracy in challenging
conditions, such as motion & low perfusion, for all patients
- it is tested to assure performance in challenging conditions,
such as drop and liquid ingress (IPX 2). Granted by US Army/Air
Force Aeromedical certification
It also features:
- audible and visual alarms
- 72 hour memory
- longest alkaline battery life: 60 hours or rechargeable battery
for 40 hours
Supplied with multilanguage cd-rom manual: GB, FR, IT, DE,
ES, PT, GR, NL, PL, NO, FI, DK, SE.
35086
35086 + 35089
WRIST OXIMETER
0123
34340
CONTINUOUS
LONG TERM
MEASUREMENT
• 34340 WRIST PULSE OXIMETER - with software
Small and lightweight wrist Oximeter available for home and clinical
long-term
and
comfortable monitoring. It can be simply worn on the patient’s wrist as a watch to start
the monitoring, and can be used during sports to measure SpO
2
and pulse rate (PR).
- audible and visual alarm with adjustable alarm limits
- trend review function of SpO
2
and PR
- selectable storage modes: 1 group/1s, 1 group/4s, and 1 group/8s
- up to 500 hour storage for SpO
2
and PR data in default mode (1 group/8s)
- clock setting and date display function
- software to download and store all measurements on PC
integrated
- removable finger probe
Size: 55x120x30 mm
Weight 300g with battery
• 35060 MINDRAY PM-60 PULSE OXIMETER
PM-60 is a miniature, lightweight device capable of
spot-
check and continuous monitoring of SpO
2
and pulse rate.
Spot Check Mode
- auto-standby and power off during the idle status
- auto-increase the patients IDs
- non-alarm setting for “sensor off“ occasion
1-99 IDs for maximum 4,000 sets of measurements
Continuous monitoring mode
- regular alarm handing
- enable to input patient ID manually
- view SpO
2
waveform for maximum 96 hour trend
Other features
- suitable for adult and pediatrics patients
- high resolution 2.4" colour LCD display
- adjustable visual and audible alarms
- real-time data transfer by infrared technology
- choose between Litium-ion or AA alkaline batteries
(for up to 36 hours continuous working) depending on
your run-time needs
- protective cover perfect for portable monitoring needs
Supplied with adult reusable sensor
• 35062 PROTECTIVE COVER - light blue
• 35063 DATA MANAGEMENT KIT
• 35064 BATTERY CHARGING KIT (EU)
Li-ion battery + charge stand + power cable
• 35065 PEDIATRIC REUSABLE SENSOR
35060
+
35062
